Zero Export self-consumption systems

The self-consumption kit for currents greater than 65A (code AAX5018) is required in order to control the PV inverter operation to guarantee that it does not export energy to the grid. This system has been certified by an external laboratory in accordance with the UNE 217001:2015 IN standard.

Self-consumption systems with energy injection to the grid

The INGECON SUN 100TL PV inverter enables to monitor the energy generated at the installation. Optionally, the self-consumption kit for currents greater than 65A (code AAX5018) allows for an advanced system monitoring in order to access all the information related to the energy self-consumed and the energy injected to the grid via the INGECON SUN Monitor PC and Smartphone application.



Current and voltage transformers

Current transformers are required for the wattmeter to perform an indirect measure, as the current is greater than 65A. A voltage transformer will be needed for those systems that want to connect the self-conumption kit directly to the medium voltage side of the installation. None of these transformers are supplied by Ingeteam.



Technical information



Datasheets

Solar self-consumption brochure
