Anticipating complex grid issues with advanced simulation models

Throughout the world, a broad range of grid codes are in constant evolution. As the amount of renewable power deployed globally continues to increase steadily, the critical issue of grid stability also become increasingly complex. Ingeteam’s advanced simulation models are the answer to the complex grid issues that come with a high penetration of wind power in transmission grids.


Using complex modelling to solve grid connectivity and stability challenges

Each wind farm grid conditions pose specific grid issues. The main challenges to grid stability and connectivity include the need to work with very low Short Circuit Ratio (SCR) or quality factor grids, as well as the existence of sub-synchronous and parallel resonances. To overcome these issues, it is indispensable to develop an accurate modelling of the converter control loops, and its interaction with the grid through the use of Linear Time-Invariant (LTI) strategies.

Advanced Simulation Models

Both Software in the Loop (SiL) and Hardware in the Loop (HiL) systems are commonly used in the industry, but the advanced simulation models developed by Ingeteam as Linear Time-Invariant (LTI) allow for higher agility to run parameter sweeps and to test new algorithms.

With the use of one state-space matrix, the stability and dynamic behaviour of the system can be obtained easily from the LTI model. To achieve this, Ingeteam characterizes all possible casuistic of the grid parameter variations and conditions, generates the LTI models for all the cases, and validates the solution through SiL and HiL systems.


Icon Module

Running advanced simulation models

  • Linear Time-Invariant (LTI) strategies
  • Software in the Loop (SiL) and Hardware in the Loop (HiL) simulation
  • Validation of simulation models
Icon Firmware

Maintaining grid quality

  • Integration with very low Short Circuit Ratio (SCR) grids
  • Stability for Sub-Synchronous (SSR) and Parallel resonances
  • Performance analysis for the use of capacitor banks
Icon Certified

Developing a strong control structure

  • Optimization of control structure
  • Improvement of dynamical behaviour
  • Validation of control loops

Free download

Discover how to solve grid connectivity & stability challenges

Ingeteam: a reliable and innovative partner

Ingeteam continuously works on the development of advanced technical solutions that optimize the performance of its power converter products.

Our industry-leading technical knowledge, acquired through more than 29,000 power converters installed in wind farms worldwide, enables us to solve the most demanding technical challenges facing the wind energy sector.

Our company currently has over 50GW of electrical wind power conversion equipment installed worldwide. Our wind power converters are efficiently operating in a high diversity of grids, each of them with specific conditions. In all situations, the key requirements of stability and connectivity are met.
